ClearBrite® Finish

Infinite possibilities in aluminum finishing solutions

ClearBrite® Finish

Description

In choosing material for louver and reflector-style lighting systems, it’s only appropriate to make an enlightened decision. Coil-anodized aluminum from Lorin Industries is that decision –because it performs beautifully in those applications and for solar concentrator panels as well - both on the job, and on the bottom line.



Lorin’s ClearBrite® finish was developed to provide lighting designers with a lower cost specular finish that has a total reflectance greater than 85% minimum and for applications needing stringent forming requirements.

Applications

  • Parabolic Louvers
  • High Intensity Reflecting
  • Solar Reflectors
  • Stadium Lights
  • Lighting Sconces
  • Brake Lights
  • LED Light Reflectors

Aluminum Properties

  • Alloy: 5657
  • Temper: H25
  • Finish: OSB

Mechanical Properties

  • UTS:
  • 20ksi [138MPa]-28ksi [193MPa]
  • YTS: Not Applicable
  • Elongation: 8 % min
  • T Bend: 1t min

Anodize Film Thickness

  • Protective Anodize Film:
  • 0.125 mil nominal *3.2 μm+

Anodize Finish Properties

  • Optical:
  • TR - 85% min
  • Gloss: Not Applicable
  • Color : D000, Clear Anodized
  • Color Target: Not Applicable
  • UV Stable: Yes
  • Seal: S3, Duplex Seal III
  • Quality Grade: 1
  • Other: None

Chemical Properties

Si: 0.08 %
Fe: 0.10 %
Cu: 0.10 %
Mn: 0.03 %
Mg: 0.6-1.0 %
Zn: 0.05 %
Al: Remainder

Industry Standards

ClearBrite® meets NSF/ANSI Standard 51, RoHS Compliant and ISO 9001 standards.

Sustainability and LEED (Leadership in Energy and Environmental Design)

Recycled Content:
100% recyclable
Post-Consumer Content = 1.6%
Post-Industrial Content = 12.9%
Volatile Organic Compounds:
Anodized aluminum does not contain any VOC’s.
